Features:
- Four-band EQ tailored specifically for bass guitar – includes controls for Bass (below 200 Hz), Lo Mid (boost/cut at 280 Hz), Mid (boost/cut at 750 Hz), and Treble (boost/cut above 2 kHz)
- The Battalionβs distortion section delivers an awesome array of distorted bass sounds
- Distortion section features Level, Blend, Drive and Tone controls plus a dedicated footswitch
- Three signal flow modes yield unique tonal variations – pre EQ, distortion comes before EQ, post EQ, distortion comes after EQ and Dry EQ, only the dry signal mixed in with the Blend control is affected by the EQ
- Compressor with dedicated pushbutton, amount control and LED adds thump and sustain to your bass sound
- Noise Gate with adjustable threshold control eliminates noise and hum while preserving your attack and original tone
- Flexible I/O allows the Battalion to fit perfectly in any bass rig or application
- ΒΌ” input jack includes switchable 10 dB pad
- Includes a headphone ready ΒΌ” output jack plus a hardwired ΒΌ” dry output jack
- Balanced XLR output for use as a DI – the DI features dedicated level, bypass and ground lift controls
- All-analog circuitry
- EHX 9.6 VDC-200 mA power supply included
- Current Draw: 100 mA @ 9 VDC
- Dimensions in inches: 4.75(w) x 5.75(l) x 2.5(h)
- Dimensions in mm: 121(w) x 146(l) x 64(h)
